National Loop Co. 68' (6' X 28') Direct Burial Vehicle Detection Loop with 50' Lead-In for 34' Wide Driveways - X-NL34-14-50

Because it ships fully assembled in heavy-duty conduit, the National Loop Co. 68' Direct Burial Vehicle Detection Loop with 50' Lead-In is ready to lay down the moment the sub-base is graded. Once a loop detector reads its signal, the loop covers the non-contact vehicle detection that UL 325 requires as one of the two means of entrapment protection for automated gates. Crews place the loop on the prepared sub-base before paving, and the new asphalt, concrete, or gravel surface locks it in place. With the 28' side crossing the lane and about 3' of clearance per edge, and the 6' side capturing vehicles in the direction of travel, the layout fits industrial or municipal lots and large estate entrances.

Features:

• Liquid-tight conduit stands between the wire and sharp stones, chemicals, ground movement, and harsh weather
• Arrives fully assembled and ready to install under new asphalt, concrete, or gravel
• Factory-set turn count means optimal read range without any on-site adjustment
• More cost-effective than hand-wound loop installations
• Fills the non-contact detection role UL 325 assigns to vehicle loops in a 2-device entrapment protection system
• Designed for vehicle detection with gate operators, parking barrier gates, overhead doors, traffic signals, arming devices, and vehicle counters
• Wound from one continuous, non-spliced wire, leaving no splice point between the loop and lead-in to fail

Specifications:

• Loop type: Direct burial
• Total loop length: 68'
• Loop dimensions: 6' x 28'
• Lead-in length: 50'
• Wire gauge: 14 AWG
• Wire material: Polypropylene-wrapped copper wire
• Best-suited driveway width: 34'
• Manufacturer: National Loop Company (NLC)
• Made in America: Yes
